Inner Diameter
|
4.3-12mm
|
|
Paper Roll
|
2-3 Plies
|
|
Thickness
|
0.25-1mm
|
|
Cutting Length
|
120-850mm
|
|
Hub Wheel
|
Two heads
|
|
Fixing Method
|
Clamp
|
|
Production Speed
|
10-50m/min
20-30 ℃ Summer: 20-50m/min
0-10℃ degree winter: 10-35m/min
|
|
Cutting Method
|
58*38*1.5 mm circular cutting blade
|
|
Gluing Method
|
Single/double side
|
|
Blade
|
5 groups
|
|
Paper Reel Stand
|
6 plies T-bar paper reel stand
|
|
Glue System
|
2 plies independent glue tank
|
|
Main Motor
|
1.5kwx2 CH kejin
|
|
Inverter
|
3.7kw, brand: TW Delta
|
|
Servo Motor
|
1.3kw, Brand: JPN Yaskawa
|
|
Tube Sorting And Packing Machine
|
L model
|
|
Pneumatic Component
|
Brand: TW Airtac
|
|
Low- Voltage Apparatus
|
Brand: Schneider
|
|
Control System
|
Brand: CH Sunlight Machinery
|
|
Linear Guide System
|
Brand: JP THK
|
|
Required Operator
|
1-2 workers
|
|
Main Part Dimension
|
3250*1100*1450 mm
|
|
Overall Dimension
|
7200*4800*1500 mm
|
|
Weight
|
1300 kg
|
|
Glue Scraping Method
|
Independent Glue box with polyurethane scraping blade
|
|
Straw Output Method
|
Automatic
|
|
Lubricating Method
|
Automatic-giving function
|
